Why Choose Vision Tech

Fixtures & Gauges?

✅ In-house manufacturing & QC

✅ Durable, ergonomic, and precise

✅ Designed for shop-floor or lab use

✅ Customization as per GD&T or CAD

Standard Gauges

Used for GO/NO-GO inspection of holes, shafts, and external dimensions.

Relation Gauges

Ideal for ensuring feature-to-feature accuracy, often used in assembly inspection.

Master Gauges

Designed to suit unique part geometries and inspection needs.

Custom Fixtures

Used for verifying or calibrating working gauges and machines.

Standard Gauges

• Plug Gauges – for checking internal diameters

• Ring Gauges – for checking external diameters

• Snap Gauges – for external dimensions quickly

• Thread Gauges – for checking threads (internal/external)

• Taper Gauges – for taper holes or shafts

• Width Gauges - for checking keyways, slots ect

Standard gauges are precision tools designed for quick and reliable inspection of commonly used dimensions such as diameters, lengths, and threads. These include plug, ring, snap, and thread gauges, widely used across industries for Go/No-Go verification and quality control.

Functional & Relation Gauges

Functional and relation gauges are specialized tools used to verify the fit, alignment, and positional relationships between mating components. These gauges simulate actual working conditions to ensure the part functions correctly in real-world assemblies.

• Used to inspect positional tolerances, true functional fit, and assembly conditions

• Often customized based on critical mating features

• Common in automotive, aerospace, and tooling applications

• Helps verify GD&T conditions like concentricity, parallelism, and true position

• Enhances inspection speed while minimizing measurement ambiguity

Setting Master Gauges

Setting master gauges are precision reference tools used to calibrate, verify, or set measuring instruments and inspection gauges to a known standard. They ensure repeatable accuracy and consistency across inspection processes.

• Used for calibration of instruments like CMMs, VMMs, height gauges, etc.

• Includes tools like ring masters, plug masters, and height masters

• Manufactured to tight tolerances and traceable to national/international standards

• Essential for maintaining measurement integrity and quality compliance

• Widely used in labs, production, and tool rooms for instrument verification

Custom Holding Fixtures

Custom holding fixtures are tailored solutions designed to securely position complex or irregular parts during inspection or manufacturing. Built to suit your component's geometry, they enhance measurement accuracy, repeatability, and inspection speed.

• Designed specifically for unique part geometries

• Ensures stable & repeatable positioning for CMM/VMM/Scanning

• Reduces setup time and increases productivity

• Built with durable materials for long-term use

• Ideal for batch inspection, prototyping, and production runs
